Fantasea UWL-09 PRO Wide Angle Lens

Name: Fantasea UWL-09 PRO Wide Angle Lens
Brand: Fantasea
SKU: 5158
Price: 999.00 USD
Availability: OutOfStock

Fantasea | SKU: 5158

Refer & Earn

Sold out

$999.00

Shipping calculated at checkout.

Pick accessories — 90% off with your $250+ order

Start $501 pick $1252 picks

DiveCatalog Moldable Mouthpiece w/ installation for Regulators
$34.95$3.50

1
DiveCatalog.com Universal Dive Gear Hanger with Accessory Arms fits Wetsuits, Drysuits, BCDs, Backpacks
$29.95$3.00

1
DiveCatalog.com Upside Down Drysuit Hanger w/ Regulator and Accessory Hooks
$29.95$3.00

1
DiveCatalog.com Small Retractor
$24.95$2.50

1
DiveCatalog.com Heavy Duty Wetsuit and Drysuit Hanger with Extra Wide Shoulder Saver
$22.95$2.30

1

90% off applies automatically at checkout on orders of $250+ — or free for signed-in members. Not combinable with discount codes.

Payment & Security

Payment methods

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Product Information

The Fantasea UWL-09 PRO Wide Angle Lens (catalog #5158) is a 0.45X wet wide-angle conversion lens for underwater camera housings, manufactured by AOI as the UWL-09PRO. It uses a 6-element, 6-group optical design with an M67 thread mount and is depth rated to 100 meters / 330 ft.

Who it is for

This lens is for compact, mirrorless, or SLR housings with an M67 threaded lens port, used with the included Type B M67 adapter. Its 130° field of view, measured with a 28mm lens, and 0 mm minimum object distance to the front dome make it suited to wide-angle and close-focus wide-angle framing underwater.

Key details

Optical design: 6 elements in 6 groups with multi-layer AR coating on all glass elements.
Glass dome: Optical-grade glass dome with inner-surface multi-layer AR coating.
Field of view: 130° with a 28mm lens.
Magnification: 0.45X.
Minimum object distance: 0 mm to the front dome lens.
Mount: M67 thread.
Depth rating: 100 meters / 330 ft.
Barrel material: Aluminum alloy with black hard anodized finish.
Weight: 1408 g on land, 770 g underwater.
Dimensions: 139 mm (diameter) by 99 mm (height).

Compatibility and sizing

The UWL-09 PRO mounts to M67 threaded lens ports using the included Type B M67 adapter and Allen key.

What's in the box

Neoprene dome front cover (DNC-04)
Rear lens cap (LRC-02)
Lens secure line (LSL-02)
Type B M67 adapter with Allen key (UWL-09P-Type B)
Carry case (LPC-02)

DiveCatalog.com is an authorized Fantasea dealer and a dive shop in Irvine, California, open since 2003. Call or chat with our team at 888-701-4017 if you have questions about port compatibility or fit for your housing.

⚠️ WARNING: This product contains chemicals known to the State of California to cause cancer, birth defects, or other reproductive harm. For more information, visit www.P65Warnings.ca.gov.

Frequently Asked Questions

Will the UWL-09 PRO fit my underwater housing's lens port?

The lens mounts via an M67 thread using the included Type B M67 adapter and Allen key. Check your housing's port thread before ordering.

Is the Fantasea UWL-09 PRO the same lens as the AOI UWL-09PRO?

Yes. The Fantasea UWL-09 PRO, catalog number 5158, is manufactured by AOI and shares the same specifications as the AOI UWL-09PRO, including the 6-element, 6-group optical design, 0.45X magnification, and 100 meter depth rating.

How deep can the UWL-09 PRO lens be used?

It is depth rated to 100 meters, or 330 ft, so it can be used on dives within that depth range on a compatible underwater camera housing.

What is included with the UWL-09 PRO wide angle lens?

The lens ships with a neoprene dome front cover, a rear lens cap, a lens secure line, a Type B M67 adapter with Allen key, and a padded carry case for storage and transport.

86%

(1177)

(114)

(37)

(16)

(31)

Excellent wetsuit but will it crush quickly like other wetsuits?

I purchased a BARE 5mm Reactive wetsuit (open box), which was like new, to replace my 1.5 yr old BARE 5mm Velocity wetsuit which had collapsed to only 2.5mm after 3 diving trips (~100 dives). The Reactive wetsuit is well constructed and very flexible. I had to increase the size of the Reactive suit, as it was smaller than the BARE Velocity suit of the same size. Tremendous customer service by Dive Catalog to exchange the wetsuit for proper size. I hope the Reactive suit does not crush so quickly like my other wetsuits (BARE, Henderson, Pinnacle). Hoping that the new technology in this suit will keep me warm below the thermocline.

Perfectly Built

Best of the many many diver hangers in my life. Easily supports my steel-plated BCD, while still donned with all of my accessories. No cracks, bends, or dents. Has even supported my BCD w/ a steel 100 tank attached (not recommended, for safety purposes, though).

Will continue to use this hanger for the long-term. No brainer.

Go-to Dive Hanger

This is a must-have for every diver. It's the quintessential hanger for all dive gear in one small package.

DiveCatalog's "Quick Dry Multi Accessory Dive Gear Hanger for Boots, Gloves, Hood" is set at a great price for a great product. Versatile enough that I've purchased extra hangers to organize my BMX racing gear.

Must-have for divers and anyone looking to organize their adventurous outdoor activities equipment.

Solid Hanger w/ Tons of Options

Does it's job and then some. The added accessory arms gives you options for a multitude of storage solutions. Solid build, solid pricing, must have for owns of dive gear.

New to this hanger...Now I'm a believer

Used tons of dive hangers, but never an upside down hanger. Game-changer for me. Will now add more of these in the near-future.

With it's swivel head design, it can cram itself into my tight dive locker, while still donning a ton of gear.

DiveCatalog's "Upside Down Drysuit Hanger w/ Regulator and Accessory Hooks" is a great product with solid construction at an affordable price. All of that with Dive Catalog's customer support/satisfaction guarantee.

Brand	Fantasea (manufactured by AOI)
Model	UWL-09 PRO (AOI UWL-09PRO)
MPN	5158
Lens Construction	6 Elements in 6 Groups
Lens Coating	Multi-layer AR coating on all glass elements; optical-grade glass dome with inner-surface multi-layer AR coating
Field of View	130° (with 28mm Lens)
Magnification	0.45X
Minimum Object Distance	0 mm to the Front Dome Lens
Mount System	M67 Thread
Depth Rating	100 Meters / 330 Ft.
Lens Barrel Material	Aluminum Alloy with Black Hard Anodized
Weight (Land)	1408 g
Weight (Underwater)	770 g
Dimensions	139mm (D) X 99mm (H)
